How to Level a John Deere Riding Lawn Mower Deck
When mowing around your home and businesses, pay attention to the recently mowed lawn. If you notice ridges forming where you recently mowed, the deck on your lawn mower may not be leveled. Luckily, leveling your mower deck is not a time consuming task, allowing you to get back to cutting the grass in no time.

Before performing any maintenance on your riding lawn mower, refer to your owner’s manual for maintenance and safety information. Maintenance instructions vary by model. Depending on your riding lawn mower model, our instructions may vary slightly so refer to your owner’s manual for more specific instructions.

Before you begin leveling your lawn mower deck follow these safety instructions. Park your mower on a hard, flat surface and shut the engine off. Set the parking brake to prevent your machine from rolling back, injuring you or others. Remove the ignition key to prevent accidental starting and wear heavy leather gloves since you’re working near mower blades.

Tools you’ll need:

  • Exact Adjust wrench
  • 18 mm wrench
  • Tire pressure gauge
  • Mower gauge
Here’s what to do:

Before starting, make sure the tires on your John Deere mower are inflated. Check your owner’s manual for information on tire pressure numbers.

John Deere Tractors

Raise the mower and place the mower cutting height knob at the position specified for deck leveling. Lower the mower and check that the mower wheels are not making contact with the ground and raise if necessary. Place the mower gauge under the mower at the adjustment point near the left rear corner. If your tractor does not make contact with the gauge, adjust the deck accordingly.

Check the mower front to back level at the front adjustment point on the front left deck hanger bracket. If necessary, use the 18 mm wrench to loosen the rear nuts on each of the front lift rods. Turn the nuts on each side until the gauge slips under the front adjustment point.

Fully raise the tractor and adjust the height control knob to the desired height, then lower the machine. Adjust the wheels so they’re at least 1/4 inch off the ground. The wheels will carry the mower deck over higher areas in the lawn to give it an even cut.

John Deere Zero Turns

Make sure the mower is parked and then mount the mower. Raise the deck into the transport position. Make sure the anti-scalp wheels are not making contact with the ground.

Lower the deck to 76 mm (3 inches). Position the right mower blade on the discharge side in the front to rear position. Once the blades are in the correct position, measure the distance between the front blade tip to the ground. Use the mower gauge to check the mower blade level. The front blade tip should be 76 mm, with a tolerance of +/- 2 mm.

Move to the other side of your zero turn and position the mower blade in the front to rear position. Measure the blade’s tip to make sure it is 76 mm as well.

If one side is lower than the other, loosen the jam nut on the adjustment rod and turn the rod tube as needed to bring the tip into the proper position. When satisfied, lock the jam nut to secure the setting. Re-check both sides of the deck after the adjustment has been made to ensure it is within specification.
